STMicroelectronics BAT54JFILM image
Images are for reference only

BAT54JFILM

STMicroelectronics Schottky Diode, 300mA, 40V, SMD, SOD-323, 2-Pin

Other Names:BAT54JFILM

more
BAT54JFILM
BAT54JFILM

Manufacturer:STMicroelectronics

Manufacturer Part:BAT54JFILM

Email Document
ECAD Model:

In Stock

72,143 In stock, ready to ship

Quantity

10

Unit Price (USD)

$0.0812

Ext. Price (USD)

$0.81

Total price$0.81
MOQ10Mult1SPQ3,000DC22+
Pricing (USD)
QUANTITYUNIT PRICE (USD)EXT PRICE (USD)
1
$0.0812
$0.08
200
$0.056
$11.20
1,500
$0.051
$76.50
3,000
$0.0476
$142.80
Volume discounts available for larger quantities.
Get Quote

Specifications

Documents

Product Compliance

AttributeValue
Category Name
Manufacturer
Capacitance @ Vr, F
10pF @ 1V, 1MHz
Current - Average Rectified (Io)
300mA
Current - Reverse Leakage @ Vr
1 µA @ 30 V
Reverse Recovery Time (trr)
5 ns
Voltage-DC Reverse (Vr) (Max)
40 V
Voltage - Forward (Vf) (Max) @ If
900 mV @ 100 mA
Operating Temperature - Junction
-40°C ~ 150°C
Package/Case
SC-76, SOD-323
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Base Product Number
BAT54
Mounting Type
Surface Mount
Rid
1037673
Series
-
Speed
Fast Recovery =< 500ns, > 200mA (Io)
Supplier Device Package
SOD-323
Technology
Schottky

Certifications

top50
9001
ilac
db
sme500

Frequently Asked Questions (FAQs)

The STMicroelectronics BAT54JFILM ordering information lists this exact order code with marking 86, SOD-323 package, 5 mg weight, 3000 base quantity, and tape and reel delivery mode. The manufacturer datasheet also indicates that J corresponds to SOD323 and that “FILM” refers to tape and reel packing. A BAT54JFILM-HQ entry is also listed with SOD-323, marking 86, 5 mg weight, and 10000 base quantity.
