Samtec STMM-120-02-F-D-RA image
Images are for reference only

STMM-120-02-F-D-RA

40-Pin 2mm Pitch 2-Row Header Push-Pull 3A Gold TH

Other Names:STMM-120-02-F-D-RA

Manufacturer:Samtec

Manufacturer Part:STMM-120-02-F-D-RA

Email Document
ECAD Model:

Available Stock

Available to order:12
Estimated Ship Time:6-13 working days

Quantity

2

Unit Price (USD)

$7.4865

Ext. Price (USD)

$14.97

Total price$14.97
MOQ2Mult1SPQ1
Pricing (USD)
QUANTITYUNIT PRICE (USD)EXT PRICE (USD)
1
$7.4865
$7.48
12
$6.622
$79.46
24
$6.4152
$153.96
60
$6.3072
$378.43
108
$5.4756
$591.36
252
$5.292
$1,333.58
504
$4.9788
$2,509.31
1,008
$4.6548
$4,692.03
Volume discounts available for larger quantities.
Get Quote

Specifications

Documents

Product Compliance

AttributeValue
Category Name
Manufacturer
Voltage Rating
-
Operating Temperature
-55°C ~ 125°C
Connector Type
Header
Contact Type
Male Pin
Termination
Solder
Current Rating (Amps)
3A
Contact Finish-Mating
Gold
Contact Finish - Post
Tin
Contact Finish Thickness - Mating
3.00µin (0.076µm)
Contact Finish Thickness - Post
-
Contact Material
Phosphor Bronze
Insulation Material
Liquid Crystal Polymer (LCP)
Material Flammability Rating
-
Packaging
Tube
Shrouding
Shrouded - 4 Wall
Contact Length - Mating
0.120" (3.05mm)
Contact Length - Post
0.090" (2.29mm)
Contact Shape
Square
Insulation Color
Black
Insulation Height
0.236" (6.00mm)
Mated Stacking Heights
-
Overall Contact Length
-
Pitch - Mating
0.079" (2.00mm)
Row Spacing-Mating
0.079" (2.00mm)
Applications
-
Ingress Protection
-
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Base Product Number
STMM-120
Fastening Type
Push-Pull
Features
Keying Slot
Mounting Type
Through Hole, Right Angle
Number of Positions
40
Number of Positions Loaded
All
Number of Rows
2
Rid
8424205
Series
Flex Stack, STMM
Style
Board to Cable/Wire
