TDK ZCAT3035-1330-BK image
Images are for reference only

ZCAT3035-1330-BK

125mm2 30mm 30 base mount 39mm*30mm*30mm

Other Names:ZCAT30351330BK

more
ZCAT3035-1330-BK
ZCAT3035-1330-BK

Manufacturer:TDK

Manufacturer Part:ZCAT3035-1330-BK

Email Document
ECAD Model:

In Stock

2,693 In stock, ready to ship

Quantity

1

Unit Price (USD)

$2.7028

Ext. Price (USD)

$2.70

Total price$2.70
MOQ1Mult1SPQ40DC2621+
Pricing (USD)
QUANTITYUNIT PRICE (USD)EXT PRICE (USD)
1
$2.7028
$2.70
10
$2.1335
$21.33
30
$1.8141
$54.42
100
$1.6837
$168.37
400
$1.6209
$648.36
Volume discounts available for larger quantities.
Get Quote

Specifications

AttributeValue
Category Name
Datasheet
RoHS
Compliant
Package / Case (Metric)
Mounting Type
base mount
Application Level
Industrial
Product Status
On sale
SPM
bulk
Operating Temperature
-40℃~85℃
Length/Width/Height
39mm*30mm*30mm
Core Factor (ΣI/A)
-
Core Material
30
Diameter
30mm
Effective Area (Ae)
-
Effective Permeability
-
Inductance Factor (AL/AI)
-
Initial Permeability
-
Magnetic Path Length
-
Magnetic Volume
-
Magnetic Cross-Sectional Area
125mm2
Tolerance
-

Certifications

top50
9001
ilac
db
sme500

Frequently Asked Questions (FAQs)

The TDK ZCAT3035-1330-BK supports EMI suppression by adding ferrite-core impedance around a cable line. For the ZCAT3035-1330(-BK) entry, the datasheet lists minimum impedance of 80 Ω from 10 to 100 MHz and 150 Ω from 100 to 500 MHz, measured under the stated condition using a ø1 mm copper wire. Use these frequency bands, cable diameter, and operating temperature limits when checking suitability for a specific design.
