Samtec SSW-108-02-S-T-RA image
Images are for reference only

SSW-108-02-S-T-RA

Connector Receptacle 2.54mm 3 Pos 24-Pin 5.7A 760nm Gold Black Bracket Mount, TH 20.83mm L × 15.31mm H

Other Names:SSW-108-02-S-T-RA

more
SSW10802STRA

Manufacturer:Samtec

Manufacturer Part:SSW-108-02-S-T-RA

Email Document
ECAD Model:

Available Stock

Available to order:54
Estimated Ship Time:6-13 working days

Quantity

3

Unit Price (USD)

$5.589

Ext. Price (USD)

$16.76

Total price$16.76
MOQ3Mult1SPQ1
Pricing (USD)
QUANTITYUNIT PRICE (USD)EXT PRICE (USD)
1
$5.589
$5.58
54
$4.9464
$267.10
108
$4.7736
$515.54
513
$4.4388
$2,277.10
1,026
$4.2444
$4,354.75
Volume discounts available for larger quantities.
Get Quote

Specifications

Documents

Product Compliance

AttributeValue
Category Name
Manufacturer
Voltage Rating
-
Operating Temperature
-55°C ~ 125°C
Connector Type
Receptacle
Contact Type
Forked
Termination
Solder
Current Rating (Amps)
4.7A per Contact
Contact Finish-Mating
Gold
Contact Finish - Post
Tin
Contact Finish Thickness - Mating
30.0µin (0.76µm)
Contact Finish Thickness - Post
-
Contact Material
Phosphor Bronze
Insulation Material
Liquid Crystal Polymer (LCP)
Material Flammability Rating
UL94 V-0
Packaging
Tube
Contact Length - Post
0.100" (2.54mm)
Contact Shape
Square
Insulation Color
Black
Insulation Height
0.295" (7.50mm)
Mated Stacking Heights
-
Pitch - Mating
0.100" (2.54mm)
Row Spacing-Mating
0.100" (2.54mm)
Applications
-
Ingress Protection
-
Moisture Sensitivity Level (MSL)
Not Applicable
Base Product Number
SSW-108
Fastening Type
Push-Pull
Features
-
Mounting Type
Through Hole, Right Angle
Number of Positions
24
Number of Positions Loaded
All
Number of Rows
3
Series
SSW
Style
Board to Board or Cable
