TDK VLCF5020T-2R7N1R7 image
Images are for reference only

VLCF5020T-2R7N1R7

Inductor 2.7μH 1.76A 71mΩ ±30% 2020 SMD 5mm × 5mm × 2mm

Other Names:VLCF5020T2R7N1R7

more
VLCF5020T-2R7N1R7

Manufacturer:TDK

Manufacturer Part:VLCF5020T-2R7N1R7

Email Document
ECAD Model:

In Stock

83 In stock, ready to ship

Quantity

10

Unit Price (USD)

$0.165

Ext. Price (USD)

$1.65

Total price$1.65
MOQ10Mult1SPQ500DC2203+
Pricing (USD)
QUANTITYUNIT PRICE (USD)EXT PRICE (USD)
10
$0.165
$1.65
100
$0.1414
$14.14
300
$0.1238
$37.14
1,000
$0.1042
$104.20
5,000
$0.099
$495.00
Volume discounts available for larger quantities.
Get Quote

Specifications

Documents

Product Compliance

AttributeValue
Category Name
Manufacturer
Frequency - Self Resonant
-
Inductance
2.7 µH
Inductance Frequency-Test
100 kHz
Q @ Freq
-
Current - Saturation (Isat)
1.76A
Operating Temperature
-40°C ~ 105°C
Current Rating (Amps)
1.76 A
DC Resistance (DCR)
71mOhm Max
Material - Core
Ferrite
Height-Seated (Max)
0.079" (2.00mm)
Package/Case
Nonstandard
Size / Dimension
0.197" L x 0.197" W (5.00mm x 5.00mm)
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Shielding
Shielded
Mounting Type
Surface Mount
Ratings
-
Rid
1132620
Series
VLCF
Supplier Device Package
-
Tolerance
±30%
