NL322522T-220J
Manufacturer: TDK
Part Number: NL322522T-220J
Please send a quick inquiry, we will reply immediately.
| Attribute | Value |
| cate_name | SMD Inductors |
| Datasheet | NL322522T-220J TDK |
| rohs | |
| reference_package | 1210 |
| mounting | PCBinstall，SMD mount |
| application_level | Industrial |
| lifecycle | |
| spm | Tape & Reel |
| operating_temperature | -40℃~85℃ |
| length_width_height | 3.2mm*2.4892mm*2.2mm |
| dc_resistance | 3.7Ω |
| inductance_value | 22μH |
| quality_factor | 30 |
| rated_current | 110mA |
| saturation_current | - |
| self_resonant_frequency | 22MHz |
| test_frequency | 2.52MHz |
| tolerance | ±5% |
